The 3M™ DBI-SALA® Nano-Lok™ Connected Order Picker SRL is a smart connected fall protection system that can sense a worker’s presence on an order picker and detects their tie off status. The system provides workers and site safety managers with real-time visual and audible feedback based on tie-off status while on an order picker. An innovative and connected solution designed to promote safety & situational awareness for workers through: Multi-Sensor Technology which detects a workers presence on an order picker as well as their tie-off status to their harness dorsal D-ring and gate closure and lock detection.
The system also incorporates Bluetooth™ communication to relay tie-off status between the hook and overhead box which enables the alert system to provide real-time tie-off status to workers, peers, and site safety. The alert system incorporates optimally placed visual LED lights on the vehicle in addition to an audible alert from the overhead box to remind the worker when they are not tied-off.
- Anchor Connection Type: Cab-mount Bracket
- Anchor Hook Material: Aluminum
- Brand: DBI-SALA®
- Connected Safety ID Equipped: Yes
- Harness Connection Type: Connected Carabiner
- Housing Material: Nylon Thermoplastic
- Install Type: Reusable or Permanent
- Lifeline Length (Imperial): 11 ft
- Lifeline Length (Metric): 3.35 m
- Lifeline Material: Dynema Webbing
- Overall Length: (Imperial) 11 ft
- Overall Length: (Metric) 3.35 m
- Product Color: Blue
- Product Type: Connected Order Picker Self Retracting Lifeline System
- Recommended Application: Powered Industrial Truck Order Picking
- Recommended Industry: General Industry, Warehousing
- Specifications Met: ANSI Z359.14 Class B, OSHA 1910.140, OSHA 1926.502
- Weight Capacity: (Imperial) 310 lb.
- Weight Capacity: (Metric) 140.61 kg
3M™ DBI-SALA® Nano-Lok Connected Order Picker SRD System User Instructions (PDF, 4.4MB)
